Introducing SmartScope® M-Series Multisensor Metrology Systems,
powered by ZONE3® Metrology Software

The next evolution
of the worldwide standard
in multisensor metrology systems

Watch the video

WHEN TIME IS THE ENEMY, TRUST OGP SMARTSCOPE M-SERIES SYSTEMS TO BE YOUR ACCELERATOR


SmartScope M-Series systems combine innovative advancements in optical technologies delivering an incredibly high-resolution image, providing you with exceptionally accurate measurement results – affording confidence to move at top speeds from line to line and part to part – for faster setups, shorter cycle times, and increased throughput.

ZONE3 Metrology Software makes difficult metrology fast and easy


OGP ZONE3 Metrology Software is the powerhouse core of SmartScope M-Series systems. ZONE3 is the world’s most comprehensive metrology software, purpose-built for multisensor metrology. Fully CAD-based, all sensors are programmed the same way, saving time both in routine building and in training. M-Series systems take full advantage of powerful ZONE3 features like Parallel Processing and Routine Optimization to achieve fast, reliable measurements.

Trusted Precision at the Speed You Need

Are you a Quality professional ready to improve your workflows and get trusted measurements? OGP SmartScope M-Series systems are for you.

Download now

Measure Fast,
Manufacture Faster

Meet Modern Multisensor Metrology

Experience Trusted Precision
with IntelliCentric-M™ Optics

As part tolerances become tighter and timelines shrink, rely on next-generation optics to deliver trusted accuracy

The patented IntelliCentric-M optical system features fixed lens optics with a 20-megapixel camera – a fully telecentric system delivering an ultra-high-resolution image with low distortion, perfect for high-speed and incredibly accurate edge detection metrology.

Speed Past
Bottlenecks

Efficiency meets ease with a multisensor system tuned for modern manufacturing

Quickly pivot from fully telecentric optics to tactile probes to laser sensors on one system. Simplify complex routines by centralizing programming. Measure parts with automatic magnification and lighting changes, to rapidly achieve highly accurate measurements – and deliver to your customers on time.

Minimize Cost
Maximize ROI

SmartScope M-Series systems are your answer for lower costs and a leaner workforce

Let one metrology system do the work of many and free your operators to oversee more lines and parts. You’ll save on space, training, calibration and maintenance. And when you’re ready for Industry 4.0, so is your M-Series system.

Close the distance between
you and your key metrics. Realize your outcomes with M-Series

  1. Trustworthy Results
    Leave no part of part inspections to chance. With true 3D multisensor measurements and fully telecentric, low distortion optics, you have definitive results you can trust.
  2. Peace-of-Mind Reliability
    For maximum uptime, count on field-tested, stable transports and the patented IntelliCentric™ optical system that offers minimized mechanical motion ⏤ contributing to less risk of repair.
  3. Easy Usability
    Make measuring hassle free by programing all sensors the same way and utilizing smart tools and automated features.
  4. Convenient Flexibility
    Address multiple metrology use cases with one machine. Combine optics, tactile probes (touch trigger and scanning), laser and micro-probes into one powerhouse system.
  5. Lightning-Fast Capabilities
    Measure entire scenes instantly with full field image processing and high-speed cameras.
  6. Cost-Effective Investment
    Save in real estate, calibration and maintenance with an all-in-one system. Reduce labor costs by training operators on a single software platform.
  7. Actionable Guidance
    Don’t just find defects; know why they happened and how to fix them, thanks to visual feedback.
  8. Future-Proof Intelligence
    Pave the way for Industry 4.0 with the M-Series systems, equipped to integrate seamlessly with robotics and model-based enterprise manufacturing techniques.

Introducing the next
evolution in smartscope

  • ZONE3 Metrology Software
    Class-leading full-3D CAD-based measurement software that’s powerful, intelligent, and easy-to-use
  • Fully 3D Multisensor Capable
    A variety of available tactile probes and non-contact laser sensors that can handle any part
  • Intellicentric-M Optical System
    Patented fixed lens, VIRTUAL ZOOM™ system offering instantaneous magnification change for fast, repeatable measurements
  • 20 MP Metrology Camera
    See every detail with remarkable image quality and improved resolution

POWERED BY ZONE3 SOFTWARE THAT MAKES
ADVANCED METROLOGY SO EASY

  • Intelligent Routine Optimization
    Run routines as efficiently as possible by reducing machine movements and measure features that can be seen at the same time simultaneously.
  • Offline Programming
    Program routines and see results at an offline workstation, eliminating the need to use a measuring machine for programming.
  • Parallel Processing
    Full field image processing allows entire scenes to be measured instantly.
  • Advanced Edge Detection Algorithms
    Class-leading algorithms allow for lightning-fast, highly accurate video measurements.

One source of truth,
countless applications

Obrázek 1

Aerospace

OGP SmartScope M-Series delivers accuracy, repeatability and reliability for both advanced inspection and reporting operations required by the Aerospace industry

Obrázek 2

Automotive/Electric Vehicles

To ensure automotive components remain within the required exacting tolerances, OGP offers advanced multisensor metrology technology with SmartScope M-Series

Obrázek 3

Energy

OGP SmartScope M-Series is equipped with multisensor technology and ZONE3 software to meet the energy industry’s precise measurement challenges

Obrázek 4

Engineering

OGP SmartScope M-Series boosts measurement throughput and minimizes lead times so engineering manufacturers can guarantee customers the highest standards of quality

Obrázek 5

Medical

SmartScope M-Series offers tailor-made solutions by integrating a variety of sensors that can measure even the smallest, most complex components to ensure critical accuracy.

Obrázek 6

Plastics

Featuring automated, non-contact video-based measuring, SmartScope M-Series provides reliable, fast and effective measurement of both simple plastic parts and more complex pieces.

Obrázek 6

Defense industry

The arms industry requires maximum precision and reliability. Our measurement systems provide the ideal solution for inspecting critical parts of weapons, optics and avionics. They are the ideal choice for demanding applications in military production where there is no room for error.
